| Place of Origin: | CHINA |
|---|---|
| Brand Name: | EVERSUN |
| Certification: | ISO,CE |
| Model Number: | EDS |
| Minimum Order Quantity: | 1set |
| Price: | negotiable |
| Packaging Details: | Standard export wooden cases |
| Delivery Time: | within 7-15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, MoneyGram, Western Union |
| Supply Ability: | 5000set/year |
| Installation: | Easy | Noise Level: | Low |
|---|---|---|---|
| Function: | Bag Unloader | Keyword: | Dumping Station |
| Dust Collection System: | Optional | Shipping: | By Sea/air Etc. |
| Service Life: | Long | Structural Material: | Carbon Steel,Stainless Steel 316L/304 |
| Product Type: | Normal/glove Box/press Bag Type | Loading Bag: | 500kg/1000kg/1500kg. |
Product description
Dust-free feeding station is the environmental protection guard of industrial production. It is equipped with a tight sealing cover, the feeding port opens and closes smoothly, and the workers are easy and convenient to feed. Internal equipped with efficient filtration system, multi-layer filter quickly adsorbed dust, purification efficiency is extremely high. The bottom conveyor is powerful and can accurately and steadily send materials everywhere. Its versatility is strong, suitable for all kinds of materials. Whether in the food, chemical or pharmaceutical fields, we can create a clean environment and improve production efficiency with excellent dust prevention and efficient transportation.
Working principle
When the dust-free feeding station is in operation, workers pour materials from the top feeding port. Instantly, the sealing cover closes the space and prevents dust from escaping. The dust air generated by the material falling is sucked into the filtration system due to the negative pressure in the equipment. The multi-layer filter screen plays a role in turn, first the primary effect filter intercepts large particles, then the medium effect and high efficiency filter captures fine dust, and the purified air is discharged through the outlet. At the same time, the screw, belt and other conveying devices at the bottom are started to push the material smoothly to the next production link, and the whole process is closely coordinated to achieve dust-free and efficient feeding.
Features & Benefits
Excellent environmental performance: Through the sealing design and efficient filtration system, it can effectively trap dust, greatly reduce the dust concentration in the working environment, meet the environmental requirements, and reduce the pollution of the atmospheric environment.
Protect the health of personnel: greatly reduce the operator's exposure to dust, reduce the risk of occupational diseases such as pneumoconiosis, and protect the health of employees.
Improve the production quality: avoid the dust pollution of the material, ensure the purity and quality stability of the material, and help to improve the quality and pass rate of the product.
Reduce operating costs: its structural design is reasonable, simple operation, easy maintenance, easy replacement of wearing parts such as filters, stable operation of equipment, low failure rate, can effectively reduce the operation and maintenance costs of equipment.
Improve production efficiency: The feeding process is smooth, and the conveying device can accurately and quickly transport the material to the specified location, reducing the material waiting time and improving the overall production efficiency.
Wide range of applications: can be customized according to different material characteristics and production needs, suitable for chemical, food, pharmaceutical, building materials and other industries, with strong versatility and adaptability.
Product parameter
| Model | Feeding port diameter | Power of blower | Air pressure of blower |
| EDS-600 | 600mm/24inch | 1.5KW | 3Kpa-25m³/m |
| EDS-800 | 800mm/32inch | 1.5KW | 3Kpa-25m³/m |
| EDS-1000 | 1000mm/40inch | 2.2KW | 3.6Kpa-39m³/m |
| EDS-1200 | 1200mm/48inch | 2.2KW |
3.6Kpa-39m³/m |
