| Place of Origin: | CHINA |
|---|---|
| Brand Name: | EVERSUN |
| Certification: | ISO,CE |
| Model Number: | ZPS |
| Minimum Order Quantity: | 1set |
| Price: | negotiable |
| Packaging Details: | Standard export wooden cases |
| Delivery Time: | within 7-15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, MoneyGram, Western Union |
| Supply Ability: | 5000set/year |
| Driving Force: | Electricity | Screening Motion: | Circular, Elliptical, Or Linear |
|---|---|---|---|
| Screening Noise: | Low | Color: | Customers' Request |
| Working Method: | Continuous Automatic | Number Of Floors: | 1-5 |
| Screen Mesh Number: | 2-500mesh | Operation Mode: | Continuous Operation |
| Function: | Screening\separation\sorting\sieving | Type: | Screening Machine |
Product description
Straight screen, an efficient screening equipment, plays a key role in industrial production. It is rectangular in appearance and compact in overall structure. The main body of the equipment is composed of a screen frame, a screen and a driving device. The screen frame is durable and can support the screen work stably. According to screening requirements, different mesh numbers can be selected to accurately separate materials. When working, the exciting force generated by the driving device makes the screen vibrate at high frequency. To screen the material from the inlet, under the action of vibration, less than the screen aperture of the material quickly through the screen to achieve efficient screening, larger than the aperture of the material is straight out along the screen, the whole process is smooth and efficient, effectively improve production efficiency, widely used in chemical, food, pharmaceutical and many other industries.
Working principle
When the screen is working, the vibration motor of the core component runs at high speed and generates strong exciting force. This exciting force is transmitted to the screen body, causing the screen to vibrate at a specific frequency and amplitude. The material to be screened enters the screen from the inlet, and under the action of vibration, the material particles continuously beat and roll. Among them, particles whose particle size is less than the screen aperture can quickly pass through the screen and fall into the collection device below to complete the screening; The material whose particle size is larger than the screen aperture cannot pass through the screen, and can only be continuously driven by vibration on the surface of the screen, move in a straight line along the inclined direction of the screen, and finally discharge from the discharge port. In this way, the in-line screen efficiently and accurately separates the material by particle size to meet the production needs of various industries.
Product Features
High screening efficiency: The unique vibration mode makes the material evenly dispersed on the screen surface and fast moving, which can effectively improve the screening efficiency and large processing capacity.
Accurate accuracy: According to different materials and screening requirements, select the appropriate mesh mesh to achieve accurate screening and ensure product quality.
Simple structure: mainly composed of screen frame, screen, vibration motor, etc., the overall structure is compact, easy to install, maintain and operate, reducing the cost of equipment and maintenance difficulty.
Good sealing: The sealing design can effectively prevent material leakage and dust flying, improve the working environment and reduce environmental pollution.
Wide range of application: can be used in chemical, food, pharmaceutical, metallurgy and other industries, for a variety of granular, powdery materials have a good screening effect.
Product parameter
| Model | Power(kw) | Sieving diameter(mm) | Dimension(mm) |
| BZP-600 | 0.12 | 520 | 740*600*560 |
| BZP-800 | 0.18 | 720 | 1010*800*600 |
| BZP-1000 | 0.18 | 890 | 1200*970*640 |
| BZP-1200 | 0.25 | 1090 | 1430*1700*700 |
| BZP-1500 | 0.25 | 1390 | 1780*1470*760 |
| Machine can be customized based on your need | |||
