Industrial screening machine

Product description
The in-line screen is an efficient screening equipment, which uses the eccentric block of the vibration motor to produce multiple overlapping forces, so that the material produces an elliptical motion track on the screen surface, so as to achieve screening. It has the characteristics of large processing capacity, strong applicability, energy saving and environmental protection, easy maintenance, etc., widely used in food, chemical, pharmaceutical, mining, building materials and other industries, can be rough screening and precision screening of various materials, playing an important role in industrial production.

Working principle
The in-line screen takes the vibration motor as the vibration source, and the eccentric block on the motor shaft rotates with the electric power of the motor, and produces centrifugal force due to the eccentricity, which causes the motor to vibrate and transfer the vibration to the screen body. When the screen body vibrates, the material on the screen surface is jointly affected by vibration and gravity, the vibration force makes it move forward by leaps, and the gravity makes it move gradually to the bottom of the screen surface, and the material less than the size of the screen falls through the screen or is directly discharged, and the material larger than the size of the screen continues to move forward and is finally discharged from the discharge port. The in-line screen is often set up with multiple layers of different screen sizes of the screen surface, the material is screened by multiple layers, large impurities are screened from the upper hole, the middle layer is screened for medium particle size materials, and the lower layer is obtained for the smallest particle size products, so as to achieve the accurate classification of the material.

Product Features
1. Efficient screening: Unique vibration mode and large discharge port design, so that the material can quickly pass through the screening surface, large processing capacity, high screening efficiency, can effectively improve production efficiency.

2. Adjustable accuracy: By changing the phase Angle and weight of the eccentric block of the vibration motor, the movement track and vibration intensity of the material can be adjusted, so as to meet the screening accuracy requirements of different materials and different particle sizes.

3. Simple structure: mainly composed of screen frame, screen, vibrator and base and other components, the overall structure is compact, reasonable design, easy installation, operation and maintenance, high reliability of the equipment, long service life.

4. Widely used: It can be applied to different materials in a variety of industries, whether it is fine materials in food, chemical, pharmaceutical and other industries, or coarse granular materials in mining, building materials and other industries, it can be effectively screened and graded.

5. Environmental protection and energy saving: low energy consumption in the operation process, and the use of sealing design, can effectively prevent dust flying and material leakage, reduce environmental pollution, in line with environmental requirements.

6. Convenient cleaning: the internal and external structure of the screen body is easy to clean, no sanitary dead corners, and the screen replacement is convenient, which can quickly complete the disassembly and installation of the screen, reducing the maintenance cost and downtime of the equipment.
Product parameter
