The design of the automatic packaging machine is advanced, with a reasonable
structure and reliable performance. It uses dual synchronous belts for film pulling,
tension controlled by cylinders, automatic correction of deviations, and an automatic
alarm protection function, minimizing losses to the greatest extent. The metering
device is integrated with the, capable of completing bag making, filling, sealing,
printing, and counting in a single operation. Additionally, the automatic packaging
machine can be modified to accommodate different by changing the metering device's
opening and closing methods. It offers various driving modes, including dual frequency
conversion, dual servo, and three-axis servo, without mechanical gearbox, ensuring
stable and reliable operation, low noise, and high tracking accuracy. It is easy to
operate, with control via a touch screen, intuitive display modular electrical design, and
digital control.





1. It can automatically complete bag making, metering, filling, sealing, cutting, and
batch number printing.
2. It uses temperature controllers to control the temperature of both the longitudinal
and transverse seals, ensuring a firm seal, good seal integrity, flat and beautiful bag
shapes, and high efficiency.
3. The bag making system uses stepper motor subdivision technology to automatically
track and locate the bag's color mark, easily completing the bag making operation with
fast and speed. It operates smoothly and quietly.
4. It uses volumetric metering, ensuring accurate metering for uniformly dense
materials, complying with national metering.
5. It allows for continuous adjustment of packaging speed within the rated range and
stops at the open mouth position.
6. It is controlled by a PLC programm controller and has a dual-language (Chinese and
English) operation interface, making the equipment easy to operate, convenient to adjust,
and highly automated.




1. Touchscreen control system, supports Chinese and English, easy and efficient
operation.

2. The vibrating feeder operates smoothly, not damage the material, and uses precise
counting control equipment to ensure accuracy, eliminating negative errors. Each feeder
in the equipment can be turned on or off as needed production.

3. Each material tray is equipped with a full material shutdown, low material alarm or
shutdown device to ensure accuracy. The equipment has a self-diagnosis, which can
automatically alarm or shut down in case of failure (users can choose to alarm or shut
down), and is equipped with multiple emergency stop buttons for convenient operation.

4. The equipment can achieve automatic arrangement, counting, filling, sealing,
packaging, conveying, selection, and boxing of materials. The number of products can
be easily adjusted, the number of bags packaged can be controlled, and the number of
packages can be automatically displayed, making it easy to calculate the machine's.

5. The equipment has reliable safety protection functions (all dangerous parts are
equipped with safety protection devices).

6. Highly compatible, it can meet the packaging requirements more than 90% of different
shaped parts on the market.

7. By adding a conveying hopper, it can support automatic packaging of various accessories,
smoother and faster movement during the conveying process, ensuring safety and low noise.

8. Equipment can be customized according to customer requirements, including the addition
of vibrating disks loaders, bag punching devices, coders, finished product conveyors, etc.
