Customizable Twin Cone Powder Particle Mixer Dust-free And Low Noise

The double cone mixer is used for mixing powders and granular materials with good

fluidity, achieving significant results. It is easy to operate, has low labor intensity,

and high work efficiency. It can mix various plants containing certain moisture, as

well as trace amounts and additives, achieving the same mixing effect. The mixing is

uniform without dead corners, it's easy to operate and maintain, runs smoothly, has

low energy consumption, no noise, long lifespan, and is lined with polyurethane or

stainless steel, ensuring no pollution.

The double cone blender is composed of a double cone cylinder, mechanical seal,

frame, delayed transmission, and stirring blades. The working process of machine

is as follows: the materials to be mixed are fed into the double cone cylinder

through vacuum conveying or manual feeding, the cylinder cover is closed, the

equipment turned on, the double cone cylinder and stirring blades rotate

simultaneously, the rotating double cone cylinder causes the materials inside the

cylinder to tumble and mix chaotically, the high-speed rotating stirring blades

break up clumped materials, allowing the materials to mix quickly within the cylinder.

The double cone blender has no dead spots or during operation, and can quickly

achieve a uniform and consistent mix of materials.

(1) The machine is driven by an electric motor, the cylinder is driven by a sprocket,

and the stirring blades are driven a V-belt. It has a simple structure, reliable

transmission, and is easy to maintain.

(2) The bearings supporting the double cone cylinder adopt mechanical dustproof

treatment, which has reliable sealing effect. Powder will not leak, and material will

not enter the bearing, leading to rapid wear and destruction of the bearing.

(3) The inlet of the double cone cylinder adopts a quick-opening rotary valve, and

the outlet adopts a large-caliber 90° rotary valve, is very convenient to use.

The double cone blender, with its excellent structure and reasonable design

concept, features rapid mixing, uniform mixing, ease of operation, convenient

cleaning,urdiness, compact structure, and high technological content. It is widely

used in industries such as pharmaceuticals, food, pesticides, zinc oxide, detergents

medicine, compound fertilizers, feed, oil, metallurgy, building materials, coatings,

dye pigments, additives, calcium carbonate, biology, ceramics, chemicals fragrance,

chicken essence, seasonings, tea, chemical building materials, coatings, plastics

and rubbers, seasonings, etc., for mixing powdered materials.
